PUMA MX2100, MX2100L

Mua ngay Gọi điện xác nhận và giao hàng tận nơi

Chi tiết sản phẩm

Multi-tasking

The combined turning center is armed with the functions of a lathe and a machining center. Complicated parts of diverse shapes can be turned only with a unit and one setup

Process-intensive Combined Turning Center– The combined turning machine having the functions of both turning and machining centers can fully turn workpieces via one setting

– Max. turning length : 1020mm(1520mm : L)

– Torque tube with a wide rib for preventing twisting and deformation

– Milling spindle and ATC device comparable to those of machining centers

– 5-axis free-form surface turning (5-axis control: option) via the 0.001 degree control (B-axis)

Thông tin kỹ thuật

Classification Unit PUMA MX2100 PUMA MX2100L
Max. Turning Diameter mm 540 540
Max. Turning Length mm 1000 Class 1500 Class
Standard Chuck Size
(Left / Right Spindle)
inch 8 / 8 8 / 8
Bar Working Diameter mm 65 65
Max. Spindle Speed r/min 5000 5000
Max. Spindle Motor Power kW 22 22
Milling Spindle Speed r/min 12000 12000
Y-axis Travel mm 170 (±85) 170 (±85)
NC System FANUC FANUC
Machining Capability Standards, S, T, ST Standards, S, T, ST
Capability Description S : Sub-spindle
T : Lower turret
S : Sub-spindle
T : Lower turret

* Product specifications are subject to change depending on additional functions and options.
