Vertical Tapping
The high-productivity tapping center is armed with high-speed spindles to enhance productivity and to minimize non-cutting time.
High Productivity Tapping Center Equipped with Dual Pallet-Maximized productivity with servo-driven Auto Tool Changer/Auto Pallet Changer and simultaneous operation control
-High reliability improved by new frame, direct-coupled spindle and servo unit
-Higher operating convenience thanks to compact machine size
Thông tin kỹ thuật
Classification | Unit | T 3600D |
---|---|---|
Travel (X / Y / Z) |
mm | 520 / 360 / 350 |
Tooling Taper | taper | 30 |
Table Size | mm | 650 x 375 (2EA) |
Max. Spindle Speed | r/min | 12000 |
Max. Spindle Motor Power | kW | 13 |
Tool Storage Capacity | ea | 14 |
NC System | – | FANUC / DOOSAN |
* Product specifications are subject to change depending on additional functions and options.
