Chi tiết sản phẩm
Model: Mynx 9500, Mynx 7500, Mynx 7500/50, Mynx 6500, Mynx 6500/50, Mynx 5400, Mynx 5400/50
Vertical High Productivity & Heavy Duty
The vertical high-durability, high-performance machining center enables powerful cutting and high-speed precision machining.
Large Size High Rigidity & Productivity Vertical Machining Center– The arch-type column structure designed to minimize deformation in heavy-duty operation and accuracy
– Higher cutting performance and productivity realized with 50-taper type, high-torque, gear-driven spindle
– Powerful and heavy-duty cutting enabled with the box guide ways on all axes
– Internal fixtures and hydraulic line options for various system applications
Thông tin kỹ thuật
Mynx 9500
| Classification | Unit | Mynx 9500 |
|---|---|---|
| Travel (X / Y / Z) |
mm | 2500 / 950 / 850 |
| Tooling Taper | taper | 50 |
| Table Size | mm | 2500 x 950 |
| Max. Spindle Speed | r/min | 6000 |
| Max. Spindle Motor Power | kW | 22 |
| Tool Storage Capacity | ea | 30 |
| NC System | – | FANUC |
Mynx 7500, Mynx 7500/50
| Classification | Unit | Mynx 7500 | Mynx 7500/50 |
|---|---|---|---|
| Travel (X / Y / Z) |
mm | 1525 / 762 / 625 | 1525 / 762 / 625 |
| Tooling Taper | taper | 40 | 50 |
| Table Size | mm | 1600 x 750 | 1600 x 750 |
| Max. Spindle Speed | r/min | 8000 | 6000 |
| Max. Spindle Motor Power | kW | 22 | 18.5 |
| Tool Storage Capacity | ea | 30 | 24 |
| NC System | – | FANUC | FANUC |
Mynx 6500, Mynx 6500/50
| Classification | Unit | Mynx 6500 | Mynx 6500/50 |
|---|---|---|---|
| Travel (X / Y / Z) |
mm | 1270 / 670 / 625 | 1270 / 670 / 625 |
| Tooling Taper | taper | 40 | 50 |
| Table Size | mm | 1400 x 670 | 1400 x 670 |
| Max. Spindle Speed | r/min | 8000 | 6000 |
| Max. Spindle Motor Power | kW | 15 | 15 |
| Tool Storage Capacity | ea | 30 | 24 |
| NC System | – | FANUC | FANUC |
Mynx 5400, Mynx 5400/50
| Classification | Unit | Mynx 5400 | Mynx 5400/50 |
|---|---|---|---|
| Travel (X / Y / Z) |
mm | 1020 / 540 / 530 | 1020 / 540 / 530 |
| Tooling Taper | taper | 40 | 50 |
| Table Size | mm | 1200 x 540 | 1200 x 540 |
| Max. Spindle Speed | r/min | 8000 | 6000 |
| Max. Spindle Motor Power | kW | 15 | 15 |
| Tool Storage Capacity | ea | 30 | 24 |
| NC System | – | FANUC | FANUC |
* Product specifications are subject to change depending on additional functions and options.
